hi,

I've kept the original implementation of dashed stroked paths as a separate commit and then the split into various xyzOp structures.

I am not completely happy with this v3 though:
- it's way too easy to forget a clip.xyzOp
- it's a bit more verbose
- I've kept the clip.Path.Close (but made a mental note of the need to get rid of it for a v4)

ie: it's more of a WIP, plea for comments than anything else.

cheers,
-s
